| Power Source |
Usable power supply unit : FV-200PS / 24 V DC (operating range : 19.5 - 27 V), M3 screw terminal |
| Current Consumption |
110 mA |
| Frequency Response |
50 Hz - 15 kHz, ±3 dB, 1 kHz |
| Distortion |
Under 1% (1 kHz, rated output) |
| Signal to Noise Ratio |
Over 60 dB |
| Audio Input |
EV : -20 dB*, 600 Ω, unbalanced, removable terminal block (2 pins) / Timer : -20 dB*, 600 Ω,unbalanced,removable terminal block (2 pins) / Paging : -60/-20 dB* (selectable), 600 Ω, balanced, removable terminal block (3 pins) / RF Link : 0 dB*, 600 Ω,unbalanced,removable terminal block (2 pins) / MIC/LINE 1 - 4 : -60/-20 dB* (selectable), 600 Ω, balanced, removable terminal block (3 pins) / AUX 1 - 2 : -20 dB*,10 kΩ, unbalanced, RCA Jack |
| Audio Output |
Priority output : 0 dB*, balanced, removable terminal block (3 pins) /BGM output : 0 dB*, balanced, Removable terminal block (3 pins) |
| Phantom Power |
MIC/LINE 1 (selectable) (+21 V DC) |
| Tone Control |
Bass : -10 dB at 100 Hz, +10 dB at 100 Hz (for INPUT BGM) / Treble : -10 dB at 10 kHz, +10 dB at 10 kHz (for INPUT BGM) |
| Muting |
MIC/LINE 1 : Mutes other input signals (Mic/Line 2 - 4, AUX 1 - 2) by 0 - 30 dB attenuation |
| Control Input |
Timer : No-voltage make contact input, open voltage : 24 V DC, short-circuit current : Under 5 mA, removable terminal block (2 pins) / Paging : No-voltage make contact input, open voltage : 24 V DC, short-circuit current : Under 5 mA, removable terminal block (2 pins) / EV : No-voltage make contact input, open voltage : 24 V DC, short-circuit current : Under 5 mA, removable terminal block (2 pins) |
| Control Output |
All Call : Contact Switch (Normally Open), removable terminal block (2 pins) |
| LED Indicator |
Power (Green) |
| Operating Temperature |
0 °C +40 °C |
| Operating Humidity |
Under 90% RH (no condensation) |
| Finish |
Front Panel : Aluminum, black, alumite |
| Dimensions |
482 (W) X 88.4 (H) X 353.3 (D) mm |
| Weight |
4.2 kg |
| Included Accessories |
Removable terminal plug (2 pins) x 7, removable terminal plug (3 pins) x 8, Instruction Manual x 1 |
